Li4Ti5O12 (Titanate) Powder for Li-ion Battery Anode, 150g/bag - Lib-LTO
Li4Ti5O12 (Titanate) Powder for Li-ion Battery Anode, 150g/bag - Lib-LTO
MPN: Lib-LTO
Li4Ti5O12 powder Coated by Carbon for high performance and stable Li-ion battery Anode. 150g/bag and vacuum sealed in plastic bag.
Carbon coating layer improves Li intercalation/deintercalation stability.
The pristine Li4Ti5O12 powder is white color, but the surface coating of carbon make it appear gray color.
Specification
|
Item |
Unit |
Content |
|
D10 |
μm |
0.2~0.6 |
|
D50 |
μm |
0.9~1.8 |
|
D90 |
μm |
≤10.0 |
|
Dmax |
μm |
34 |
|
Tap Density |
g/ml |
≥0.65 |
|
Specific Surface Area |
m2/g |
≤6.0 |
|
Purity |
% |
>98 |
|
Capacity at 0.5C discharging |
mAh/g |
>161.2 |
|
Coulomb rate at first cycle |
% |
95.5 |
|
Capacity at 1C discharging |
mAh/g |
>150.0 |
|
Capacity at 10C discharging |
mAh/g |
>126.1 |
|
Capacity at 1C Divided by Capacity at 0.5C |
% |
91.0 |
|
Material Safety Data Sheet |
Safety Data Sheet (SDS)
|
|
|
Article |
Application Notes:
-
Please click to see Procedure for Preparing Anode & Cathode Electrode Slurry.
-
Please keep the powder in vacuum box to avoid moisture.
-
Please bake the powder in a vacuum oven at 120 - 150 °C before making slurry and coating to ensure max capacity.
