Single Crystal Powder of LiNiCoMnO2 (Ni:Co:Mn=6:1:3, NCM613) Powder for Li-ion Battery Cathode, 200g/bottle - Lib-LNCM613-SC

Single Crystal LiNiCoMnO2 (Lithium Nickel Manganese Cobalt Oxide, Ni:Co:Mn=6:1:3, NCM613) with an electro-chemo-mechanically compliant microstructures has attracted great attention in Li-ion battery for its superior electrochemical performance compared to the polycrystalline counterpart

Specification

Properties	Item	Standard Value
Chemical Composition	Ni (mol%)	60.0
	Co (mol%)	10.0
	Mn (mol%)	30.0
Size Distribution	D10 (μm)	1.8
	D50 (μm)	3.5
	D90 (μm)	6.3
Specific Surface Area (m2/g)		0.84
Tap Density (g/cm³)		2.50
Moisture (ppm)		219
pH		11.56
Electrochemical Properties	First discharge specific capacity (2032 coin battery, 0.1C/0.1C, 2.8-4.25V, mAh/g)	190.8
	First charge and discharge efficiency (%)	87
Charge & Discharge Graph
Note	MTI does not manufacture this product and only sells a small quantity to research for the development of new-generation batteries. If you need a larger quantity or have a question about the IP, we will forward your inquiry to the producer.

Application Notes:

1. Please click to see Procedure for Preparing Anode & Cathode Electrode Slurry.
2. Please keep the powder in the vacuum box to avoid moisture.
3. Please bake the powder in a vacuum oven at 120 - 150 °C before making slurry and coating to ensure max. capacity.
4. The product is for research only, not supply for large quantities.
