Conductive Graphite Powder for Li-ion Battery Anode/Cathode, 80g/bag - EQ-Lib-CGP

Conductive Graphite Powder for Li-ion Battery Anode/Cathode, 80g/bag - EQ-Lib-CGP

MPN: Lib-CGP

Conductive Graphite is used as conductive material when preparing Li-ion battery Cathode and Anode. It has strong inoxidizability,
self-lubrication and plasticity as well as good conductivity and adhesion under high temperature.

Specifications:

Fixed Carbon (%)
≥99.98

Applications:

  • For preparing Li-ion battery electrode material and conducting material, for example:
    • Cathode: Cathode Powder+Conductive Graphite+PVDF+NMP
    • Anode: Anode Powder+Conductive Graphite+PVDF+NMP (or SBR+CMC)
  • Corrosion resistance to Potassium Hydroxide.
  • For anti-corrosion and high-temperature lubricant
  • For preparing carbon resister, conducting dry film and electrolyte.
  • Applied in the rub and plastic as bulking agent.
  • Applied in the raw material of alloy.
  • Applied in the chemical industry as catalyst.
Notes:
  • Please click to see Procedure for Preparing Anode & Cathode Electrode Slurry.
  • Please keep the powder in vacuum box to avoid moisture.
  • Please bake the powder in a vacuum oven at 120 - 150 °C before making slurry and coating to ensure max. capacity.
Granularity (um)
1-5
Moisture Content (%)
≤0.08
Ash Content
 ≤0.01
PH
 7±0.2
Fe
 ≤5
S
 ≤0.01
Si
 ≤1
Cl
 ≤0.1
F
 ≤1
Al
 ≤1
Cu
 ≤1
Cr
 ≤1




Material Safety Data Sheet SDS
