MTI Corporation

Single Crystal LiNiCoMnO2 (Ni:Co:Mn=9: 0.5: 0.5) Powder for Li-ion Battery Cathode, 200g/bottle - Lib-LNCM911-SC

Single Crystal LiNiCoMnO2 (Ni:Co:Mn=9: 0.5: 0.5) Powder for Li-ion Battery Cathode, 200g/bottle - Lib-LNCM911-SC

Single Crystal LiNiCoMnO2 (Lithium Nickel Manganese Cobalt Oxide, Ni:Co:Mn=9:0.5:0.5) with advantages of high tape density, long cyclability, high specific capacity, and excellent electrochemical performance consistency, has attracted great attention in Li-ion battery compared to the polycrystalline counterpart

Specification

Properties Item Standard Value


Chemical Composition		 Ni (mol%) 90.0 ± 0.5
Co (mol%) 5.0 ± 0.5
Mn (mol%) 5.0 ± 0.5
Size Distribution

D50 (μm)

 3.5 ± 1.0
Impurities (wt%)

OH-

 ≤0.30
CO32- ≤0.20
Specific Capacity (mAh/g)
  • 214 ± 3 (room temperature, 25 °C)
Coulombic Efficiency (%)
  • 87 ± 1 (first cycle)

Note		 MTI does not manufacture this product and only sells a small quantity to research the development of new-generation batteries. If you have a question about IP, we will forward your inquiry to the producer.



Application Notes:

  1. Please click to see Procedure for Preparing Anode & Cathode Electrode Slurry.
  2. Please keep the powder in the vacuum box to avoid moisture.
  3. Please bake the powder in a vacuum oven at 120 - 150 °C before making slurry and coating to ensure max. capacity.
  4. The product is for research only, not supply for large quantities.
